Basic Info.
Product Description
| Model | 16014 |
| Feature | thin wall deep groove ball bearing |
| Material | Chrome Steel (Gcr15) + G16 |
| Noise Level | Z1, Z2, Z3, Z4 |
| Precision | P0,P6,P5,P4,P2 |
| Clearance | C0,CM,C3,C4,C2 |
| No. | Size | Rated load | Weight | ||||||||||
| Inner Diameter | Out Diameter | Width (B) | Chamfering | Dynamic | Static | ||||||||
| d | D | Open Type | Shielded Type | rsmin (r) | Cr | Cr | Close | ||||||
| mm | inch | mm | inch | mm | inch | mm | inch | mm | inch | N | N | KG | |
| MR52 | 2 | 0.0787 | 5 | 0.1968 | 1.5 | 0.0590 | 2.5 | 0.0984 | 0.1 | 0.004 | 181 | 78 | - |
| MR62 | 2 | 0.0787 | 6 | 0.2362 | - | - | 2.5 | 0.0984 | 0.1 | 0.004 | 181 | 78 | - |
| MR72 | 2 | 0.0787 | 7 | 0.2756 | - | - | 3 | 0.1181 | 0.1 | 0.004 | 181 | 78 | - |
| MR63 | 3 | 0.1181 | 6 | 0.2362 | 2 | 0.0787 | 2.5 | 0.0984 | 0.1 | 0.004 | 181 | 78 | - |
| MR83 | 3 | 0.1181 | 8 | 0.3150 | 3 | 0.1181 | 4 | 0.1575 | 0.1 | 0.004 | 181 | 78 | - |
| MR93 | 3 | 0.1181 | 9 | 0.3543 | 3 | 0.1181 | 4 | 0.1969 | 0.1 | 0.004 | 181 | 78 | - |
| MR74 | 4 | 0.1575 | 7 | 0.2756 | 2 | 0.0787 | 2.5 | 0.0984 | 0.1 | 0.004 | 181 | 78 | - |
| MR84 | 4 | 0.1575 | 8 | 0.3150 | 2 | 0.0787 | 3 | 0.1181 | 0.1 | 0.004 | 181 | 78 | 0.00056 |
| MR85 | 5 | 0.1969 | 8 | 0.3150 | 2 | 0.0787 | 2.5 | 0.0984 | 0.008 | 0.003 | 181 | 78 | 0.00025 |
| MR95 | 5 | 0.1969 | 9 | 0.3543 | 2.5 | 0.0984 | 3 | 0.1181 | 0.15 | 0.006 | 332 | 142 | 0.00058 |
| MR104 | 4 | 0.1575 | 10 | 0.3937 | 3 | 0.1181 | 4 | 0.1575 | 0.15 | 0.006 | 715 | 265 | 0.00133 |
| MR105 | 5 | 0.1969 | 10 | 0.3937 | 3 | 0.1181 | 4 | 0.1575 | 0.15 | 0.006 | 460 | 196 | 0.00126 |
| MR106 | 6 | 0.2362 | 10 | 0.3937 | 2.5 | 0.0984 | 3 | 0.1181 | 0.1 | 0.004 | 460 | 196 | 0.00070 |
| MR115 | 5 | 0.1969 | 11 | 0.4331 | 4 | 0.1575 | 4 | 0.1575 | 0.15 | 0.006 | 735 | 284 | 0.00062 |
| MR117 | 7 | 0.2756 | 11 | 0.4331 | 2.5 | 0.0984 | 3 | 0.1181 | 0.1 | 0.004 | 450 | 206 | 0.00071 |
| MR126 | 6 | 0.2362 | 12 | 0.4724 | 3 | 0.1181 | 4 | 0.1575 | 0.15 | 0.006 | 774 | 329 | 0.00166 |
| MR128 | 8 | 0.3150 | 12 | 0.4724 | 2.5 | 0.0984 | 3.5 | 0.1378 | 0.1 | 0.004 | 510 | 255 | 0.00099 |
| MR137 | 7 | 0.2756 | 13 | 0.5118 | 3 | 0.1181 | 4 | 0.1575 | 0.15 | 0.006 | 715 | 265 | 0.00201 |
| MR148 | 8 | 0.3150 | 14 | 0.5512 | 3.5 | 0.1378 | 4 | 0.1575 | 0.15 | 0.006 | 715 | 265 | 0.00219 |
| MR166 | 6 | 0.2362 | 16 | 0.6299 | 6 | 0.2362 | 6 | 0.2362 | 0.15 | 0.006 | 1470 | 600 | 0.00580 |
By focusing on areas of Deep Groove Ball Bearing for over 20 years, we understand every need of our customers. Cixi JVB Bearing Company is a leading manufacturer of Deep Groove Ball Bearing in north China, Our brand is JVB. JVB Company covers an area of 170 acres, with an annual production value of more than 100 million dollars. With more than 30 production lines and new production and testing equipment, JVB controls the performance and quality of our products while maintaining production capacity. We have experienced R & D technical engineers. In 2008, we outsourced Japanese NSK engineers as consultants. Over the years JVB has independently developed high-performance precision bearings in stainless steel and engineering plastics and has obtained a number of national and international certified patent certificates. Look forward to building long-time business cooperation with you!
